JADE Pallet (J.A.D.E. — Jade Ann Design & Engineering)

Precision-built pallets. Drop-in compatible with CHEP / Red / GMA standards.

Handcrafted pallets engineered to ship, stack, and survive.

JADE Pallet handbuilds precision wooden pallets in standard footprints (48×40″ GMA, 1200×1000 mm and custom sizes). Our pallets are made using kiln‑dried lumber, heavy‑duty fasteners, and exact tolerances so they drop into existing supply chains. Perfect for warehousing, export, and display.

Explore Models

Drop‑in Compatible

Designed to match CHEP & Red footprints

Handcrafted Quality

Small‑batch builds with tight tolerances

Repair & Reuse

Refurbish cycles extend pallet life

Products & Models

Each model is available in single‑use and multi‑trip configurations. We provide interchangeability with standard pallet pooling systems.

JADE Standard (JADE‑GMA)

Footprint: 48 × 40 in — Typical GMA configuration (7 top boards, 3 stringers/blocks). Kiln‑dried hardwood, standard height ~5.6 in. Tare weight: ~38–50 lbs depending on spec.

Compatibility	CHEP / GMA / North America
Typical Static Load	Up to 3,500 lb (dependent on stacking & rating)
Dynamic Forklift Load	Up to 2,200 lb

JADE Red / Metric (JADE‑RM)

Footprint: 1200 × 1000 mm — Metric markets and export. Robust block design, export treatment available on request.

JADE Heavy & Custom

Custom builds for heavy machinery, retail displays, or branding needs. Reinforced stringers, thicker deck boards, and bolt‑in metal plates available.

Quick Specs

Top‑deck: 7 boards (standard)
Blocks: 3 full blocks (4‑way entry)
Treatment: Heat treatment (HT) available for export
Color: Raw wood, or painted JADE green for your fleet
Custom stamping & RFID tagging available

Files & Downloads

Spec sheet (PDF) — download coming soon

// Sample spec snippet
Model: JADE‑GMA
Footprint: 48 x 40 in
Top boards: 7 x 3/4" x 5.5"
Stringers/blocks: Standard
Treatment: Kiln dried / optional HT

Engineering & Specs

We match common pooling footprints so JADE pallets are drop‑in replacements. Below are our engineering notes and recommended tolerances.

Material & Fasteners

Recommended wood: Kiln dried hardwood or treated softwood (AS/NZS / ISPM15 options)
Nails: Ring shank 50 mm common nails (or galvanized screws for heavy duty)
Tolerances: Top deck deflection < 10 mm under rated dynamic load
Finish: Optional paint or branded stenciling

About JADE Pallet

JADE Pallet was born in a small workshop where years of hands‑on pallet repair and bespoke building taught us the value of tight dimensions. We build with respect for the shipping chain — pallets that fit into existing systems without surprise. Owner & founder: Jade Ann Byrne — builder, storyteller, and lifelong tinkerer.
